Hioki MR8904 CAN Unit
Use our chat for personal support. Or contact us via +46 73-202 00 59 or sales@GOmeasure.se
Analyse CAN singal module for Memory Recorders
Discover the possibilities
More information
Description
Hioki MR8904 CAN Unit
| Input CAN port | Number of ports: 2, Connector: D-sub a male 9 pin ×2 |
|---|---|
| Standards | ISO 11898 CAN 2.0b, ISO 11898-1, ISO 11898-2, ISO 11898-3, SAE J2411 |
| Interface | Selectable: High-speed CAN, Low-speed CAN, or Single-wire CAN by port (with built-in corresponding transceiver) |
| Transmit ACK | ON/OFF for transmitting a ACK for receiving CAN signal with the MR8904 |
| Terminator | ON/OFF via commands, 120 Ω ±10 Ω built-in resistance |
| Baud rate | 50 kbps to 1 Mbps at “High-speed”, 10 kbps to 125 kbps at “Low-speed”, 10 kbps to 83.3 kbps at “Single-wire” |
| Analyzed signal output channel | Up to 15 analog channels each equivalent to a 16-bit analog signalUp to 16 logic channels each equivalent to a 1-bit logic signal |
| Signal form | 1-bit signal: 1 channel of Logic, or 1 channel of Analog1-bit to 16-bits signal: 1 channel of Analog17-bits to 32-bits signal: 2 channels of Analog* Cannot handle signals over 32-bits |
| ID trigger | Output “H” level pulse to designated logic channel when receiving set ID signal* Output pulse width: 50 μs below 5 ms/div time axis, 1 sampling time at more than 10 ms/div time axis |
| Response time | Within 200 μs after completely receiving CAN message |
| Transmit CAN message | Can transmit the setting CAN message to the CAN bus by a port |
| Dimensions and mass | 119.5 mm (4.70 in)W × 18.8 mm (0.74 in)H × 151.5mm (5.96 in)D, 185 g (6.5 oz) |
| Accessories | None |
Documents
Options
Video
Hioki MR8904 CAN Unit
| Input CAN port | Number of ports: 2, Connector: D-sub a male 9 pin ×2 |
|---|---|
| Standards | ISO 11898 CAN 2.0b, ISO 11898-1, ISO 11898-2, ISO 11898-3, SAE J2411 |
| Interface | Selectable: High-speed CAN, Low-speed CAN, or Single-wire CAN by port (with built-in corresponding transceiver) |
| Transmit ACK | ON/OFF for transmitting a ACK for receiving CAN signal with the MR8904 |
| Terminator | ON/OFF via commands, 120 Ω ±10 Ω built-in resistance |
| Baud rate | 50 kbps to 1 Mbps at “High-speed”, 10 kbps to 125 kbps at “Low-speed”, 10 kbps to 83.3 kbps at “Single-wire” |
| Analyzed signal output channel | Up to 15 analog channels each equivalent to a 16-bit analog signalUp to 16 logic channels each equivalent to a 1-bit logic signal |
| Signal form | 1-bit signal: 1 channel of Logic, or 1 channel of Analog1-bit to 16-bits signal: 1 channel of Analog17-bits to 32-bits signal: 2 channels of Analog* Cannot handle signals over 32-bits |
| ID trigger | Output “H” level pulse to designated logic channel when receiving set ID signal* Output pulse width: 50 μs below 5 ms/div time axis, 1 sampling time at more than 10 ms/div time axis |
| Response time | Within 200 μs after completely receiving CAN message |
| Transmit CAN message | Can transmit the setting CAN message to the CAN bus by a port |
| Dimensions and mass | 119.5 mm (4.70 in)W × 18.8 mm (0.74 in)H × 151.5mm (5.96 in)D, 185 g (6.5 oz) |
| Accessories | None |
