RIGOL DSG821 9kHz~2.1GHz RF Signal Generator
Use our chat for personal support. Or contact us via +46 73-202 00 59 or sales@GOmeasure.se
- Frequency Range: 9kHz~2.1GHz
- Amplitude Specification Range: -110dBm~+13dBm
- SSB Phase Noise (Typ.): <-112dBc/Hz@1GHz,20kHz offset
- Modulation Type: AM/FM/ØM/Pulse
:%20%26lt;-112dBc/Hz@1GHz,20kHz%20offset%0AModulation%20Type:%20AM/FM/%C3%98M/Pulse%0A
){kind=link}
Discover the possibilities
More information
Description
Complete AM/FM/ØM Analog Modulation
DSG800 provides a variety of analog modulation functions such as AM/FM/ØM, which is suitable for signal simulation requirements in various applications such as FM radio and wireless microphone.
Pulse Modulation
It produces high quality pulse modulated signals with rise/fall times typically less than 10 ns and on/off ratios greater than 70 dB. Support for internal and external modulation. Built-in pulse generator can generate pulse sequence and output to the outside as a separate pulse generator
Low Phase Noise
High signal purity, phase noise typical value <-112dBc/Hz@20kHz; better high-stability clock reference with better near-phase noise capability.
High Amplitude Accuracy
The output amplitude accuracy is typically 0.5 dB, providing users with accurate excitation signals
Wide Range of High Power Output
The maximum output amplitude is +13dBm (nominal value), and can be set to +20dBm to meet the nonlinearity test of the amplifier.
Amplitude Stability
Reliable repeatability provides engineers with sufficient test confidence that the 72-hour output amplitude variation is less than 0.02dB
