Tekbox TBCP5-150K400 RF Current Monitoring Probe
Use our chat for personal support. Or contact us via +45 31 33 18 19 or salg@GOmeasure.dk
- Type: Passive Monitoring Loop Antenna
- Frequency range: 30 Hz–100 KHz
- Standards: MIL-STD-461G / RS101
- Loop Diameter: 4.1cm
Discover the possibilities
More information
Description
The TBCP5-150K400 is a snap-on RF current monitoring probe, expanding the Tekbox product range of affordable test equipment.
The probe has a flat response from 150 kHz to 400 MHz and is characterized over the frequency range from 10 Hz to 500 MHz. The TBCP5-150K400 is designed for RF current monitoring applications, which need very high magnetic saturation. The TBCP5-150K400 transimpedance characteristic is not influenced by bias currents as high as 200 Ampere.
The aperture of the RF current monitoring probe is 46 mm. The transfer impedance is 11 dB Ohm with a 3dB bandwidth from 150kHz to 400 MHz.
Documents
Options
Video
The TBCP5-150K400 is a snap-on RF current monitoring probe, expanding the Tekbox product range of affordable test equipment.
The probe has a flat response from 150 kHz to 400 MHz and is characterized over the frequency range from 10 Hz to 500 MHz. The TBCP5-150K400 is designed for RF current monitoring applications, which need very high magnetic saturation. The TBCP5-150K400 transimpedance characteristic is not influenced by bias currents as high as 200 Ampere.
The aperture of the RF current monitoring probe is 46 mm. The transfer impedance is 11 dB Ohm with a 3dB bandwidth from 150kHz to 400 MHz.
